TA-HWP-70T
The TA-HWP-70T is a high-performance HDMI Wall Plate Extender engineered for modern AV installations requiring reliable long-distance signal transmission. Using HDBaseT technology, it extends 4K@60Hz HDMI, RS-232, and IR control over a single CAT6 cable up to 40 meters without compromising signal quality.
Designed for meeting rooms, classrooms, training centers, hotels, and corporate environments, the TA-HWP-70T provides a clean wall-mounted HDMI input while reducing cable clutter and simplifying installation. With Plug & Play operation, HDCP compliance, and professional-grade performance, it is the ideal solution for seamless AV connectivity.
Key Features
- Extends HDMI 4K@60Hz signals up to 40 meters over CAT6 cable
- Supports HDBaseT technology for reliable long-distance transmission
- Supports 4K Ultra HD video with crystal-clear image quality
- Integrated RS-232 pass-through for remote device control
- Supports Bi-directional IR signal transmission
- HDMI wall plate transmitter with compact, professional design
- HDCP compliant for protected content playback
- Plug & Play installation with no software required
- Uses a single CAT6 cable for video, audio, and control signals
- LED status indicators for Power, HDCP, and Link status
- Professional wall-mounted installation for clean cable management
- Reliable signal transmission with low latency and high stability
Datasheet
Parameter | Specification |
Video Resolution | Up to 4K@60Hz |
Transmission Distance | Up to 40m (CAT6) |
Technology | HDBaseT |
HDMI Input | 1 × HDMI |
HDMI Output | 1 × HDMI (Receiver) |
Control | RS-232 Pass-through |
IR | Bi-directional IR |
Cable Type | CAT6/CAT6A |
Installation | Standard Wall Plate |
HDCP | Supported |
Installation | Plug & Play |
Diagram
