TA-U2ACT-AF USB 2.0 ACT AM TO AF
The USB 2.0 Active Extension Cable (USB-A Male to USB-A Female) is designed to extend USB connections beyond standard passive cable limits while maintaining stable and reliable data transmission. With an integrated active repeater chipset, this cable boosts the USB signal to prevent data loss and connection drop-outs over long distances. The cable includes external power support, ensuring sufficient and stable power delivery to connected USB devices. It is ideal for extending low-speed and full-speed USB peripherals such as keyboards, mice, printers, scanners, webcams, and touch devices in professional AV, office, and industrial environments.
Datasheet
Parameter | Specification |
Product Name | TA-U2ACT-AF |
Description | USB 2.0 Active Extension Cable (USB-A Male to USB-A Female) |
Max. data rate | Up to 480 Mbps (High-Speed) Backward compatible with USB 1.1 |
Range | 49.2 ft( 15 m) over multimode |
Connector Housing | Molded, compact design with strain relief |
Power Source | USB bus-powered Optional external DC power input (recommended for power-hungry devices) |
Hot-Swap Support | Yes |
Conductor Material | High-purity copper |
Shielding | Multi-layer shielding for EMI/RFI protection |
Jacket Material | PVC |
Cable Color | Black |
Cable diameter | 4.5 mm |
Output Voltage | 5 V DC |
Available Lengths | 5m, 10m, 15m |
Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Storage Temperature | -20°C to 70°C (-4°F to 158°F). |
Humidity | 5% to 90% (non-condensing) |
flammability | UL, VW-1 |
Compliance | CE, RoHS |
