TA-H2HPRO HDMI 2.0 CABLES
Reliable 4K Performance. Cost-Effective Solution for Everyday AV.
The TechAagam TA-H2HPRO HDMI 2.0 Pro Series Cable is designed for dependable Ultra HD audio and video transmission in standard AV installations. Delivering stable 4K @ 60Hz performance with 18Gbps bandwidth, the MC36 series provides consistent signal transmission for residential and commercial applications where reliability and value are equally important.
Built with quality OFC conductors, effective shielding, and gold-plated HDMI connectors, the TA-MC36 ensures secure connectivity and long-lasting performance in meeting rooms, classrooms, digital signage setups, and home entertainment systems.
Key Highlights
- Supports 4K Ultra HD @ 60Hz
- 18Gbps HDMI 2.0 bandwidth
- HDR10 support
- Gold-plated HDMI connectors for improved signal reliability
- Shielded construction to reduce EMI/RFI interference
- Molded connectors with strain relief
- Supports 3D, CEC, ARC, and HEC
- HDCP 2.2 compliant
- Plug-and-play operation
- Backward compatible with earlier HDMI versions
Ideal Applications
- Corporate Meeting Rooms
- Training Rooms & Classrooms
- Digital Signage Displays
- Home Theater & Residential AV
- AV Receivers & Soundbars
- Control Rooms & General AV Installations
Technical Overview
- HDMI Version: 2.0
- Maximum Bandwidth: 18Gbps
- Maximum Resolution: 4K × 2K @ 60Hz
- HDR Support: HDR10
- Audio Support: Dolby TrueHD, DTS-HD Master Audio
- Color Depth: Up to 36-bit Deep Color
- Connector Type: HDMI Male to Male
- Jacket Material: PVC
- Compliance: CE, RoHS | UL VW-1
Available Lengths
1.8m | 3m | 5m | 7.5m | 10m | 15m
Part numbers follow the TA-H2HPRO series structure.
Datasheet
Parameter | Specification |
Series HDMI | TA-H2HPRO SERIES HDMI Cable |
Version | HDMI 2.0 |
Maximum Bandwidth | 18Gbps |
Maximum Resolution | 4K × 2K @ 60Hz (4:4:4) |
HDR Support | HDR10 |
Audio Formats | Dolby TrueHD, DTS-HD Master Audio |
HDCP Compliance | HDCP 2.2 |
Color Depth | Up to 36-bit Deep Color |
Connector Type | HDMI Male to HDMI Male |
Cable Type | 30awg(1m - 3m),28awg(5m - 7.5m),26awg(10m - 20m) |
Conductor size | Passive HDMI Cable |
Shielding | Shielded construction |
Jacket Material | PVC |
Supported Features | 3D, CEC, ARC, HEC |
Outer Diameter (OD) | 30awg-6.2mm, 7.5m-28awg-7.5mm, 26awg-8.5mm |
Available Lengths | 1m, 1.8m, 3m, 5m, 7.5m, 10m, 15m, 20m |
Compliance | CE, RoHS |
flammability | UL, VW-1 |
Operating | 0° C to +50 °C 0 |
Humidity | 0 % to 80 % RH |
